Shenzhen Coastal Trading Co.,Ltd.
品牌:Christian Bauer
型号:
采购热线:0755-86216601
13714972229
德国进口,中国没有库存,一次订货量不少于500个。
要几十个的无法提供 谢谢!.........
深圳市湾边贸易有限公司提供弹簧垫片,盘形弹簧,蝶形弹簧垫片,碟形弹簧垫片;
盘形弹簧,蝶形弹簧垫片,碟形弹簧垫片(Disc springs)其形状为圆锥盘状,用于安装空间小,而
且需要大负荷之重机械或模具。目前欧、美、?等先进国家的工程师在
机械组件的使用?,已将盘形弹簧大量应用,除了安全性的考量,也取
?原先传统螺旋弹簧使用空间和负荷?限及压缩行程过大等缺点,并提
高机械之性能。
应用范围
※动力传输组件,如离合器、剎车系统、磁盘驱动器传动轴…等。
※电气系统传动开关装置之组件。
※切削?心机、钻孔机、控制阀、球阀…等。
※管路输送系统、管路支架及冲床等螺柱、螺丝弹性垫圈。
※升降机、起重机、堆高机…等重机械之组件。
※?动化机械之组件,如编织机、?刷…等。
※大型电动马达、汽油压涡轮、柴油引擎、帮浦…等组件。
※手工具、园艺工具及农业机械,如剪草机、牵引机…等。
※冲床模具、轴承预压用、油封。
※航空器、机车、?行车等座椅之组件。
材质(DIN2093)
Ck67 :使用于厚度小于1.25mm的盘形弹簧
50CrV4:所?DIN盘形弹簧均
用材质(DIN2093)
Ck67 :使用于厚度小于1.25mm的盘形弹簧
50CrV4:所?DIN盘形弹簧均用
※另?不锈钢AISI 301、AISI 631详细规格,请来电洽询!
※ 另?不锈钢AISI 301、AISI 631详细规格,请来电洽询!
盘形弹簧,蝶形弹簧垫片,碟形弹簧垫片(Disc springs)其形状为圆锥盘状,用于安装空间小,而
且需要大负荷之重机械或模具。目前欧、美、?等先进国家的工程师在
机械组件的使用?,已将盘形弹簧大量应用,除了安全性的考量,也取
?原先传统螺旋弹簧使用空间和负荷?限及压缩行程过大等缺点,并提
高机械之性能。
订货号 下底*上底*厚*高mm 下底*上底*厚*高mm
Teile-Nr.112606 375x191.2x20.8 (20.8) 29.0 0.42 375*191.2*20.8 (20.8) 29.0 0.42
Teile-Nr.112605 355x181.2x19.7 (19.7) 27.5 0.42 355*181.2*19.7 (19.7) 27.5 0.42
Teile-Nr.112604 335x171x18.6 (18.6) 25.9 0.42 335*171*18.6 (18.6) 25.9 0.42
Teile-Nr.112603 315x161x17.5 (17.5) 24.4 0.42 315*161*17.5 (17.5) 24.4 0.42
Teile-Nr.112602 300x151x16.7 (16.7) 23.3 0.42 300*151*16.7 (16.7) 23.3 0.42
Teile-Nr.112601 280x141x15.5 (15.5) 21.7 0.43 280*141*15.5 (15.5) 21.7 0.43
Teile-Nr.112600 265x136x14.7 (14.7) 20.5 0.42 265*136*14.7 (14.7) 20.5 0.42
Teile-Nr.105240 250x127x16 (15.1) 21.8 0.48 250*127*16 (15.1) 21.8 0.48
Teile-Nr.105239 250x127x14 (13.1) 19.6 0.54 250*127*14 (13.1) 19.6 0.54
Teile-Nr.105235 250x127x12 (11.3) 19.3 0.75 250*127*12 (11.3) 19.3 0.75
Teile-Nr.105220 225x112x6.5 (6.2) 13.6 1.24 225*112*6.5 (6.2) 13.6 1.24
Teile-Nr.105219 225x112x6.0 (6.0) 13.6 1.34 225*112*6.0 (6.0) 13.6 1.34
Teile-Nr.105199 200x102x5.5 (5.5) 12.5 1.35 200*102*5.5 (5.5) 12.5 1.35
Teile-Nr.105179 180x92x10 (9.4) 14.0 0.53 180*92*10 (9.4) 14.0 0.53
Teile-Nr.105177 180x92x6.0 (5.6) 11.1 1.04 180*92*6.0 (5.6) 11.1 1.04
Teile-Nr.105174 180x92x4.8 (4.8) 11.0 1.37 180*92*4.8 (4.8) 11.0 1.37
Teile-Nr.105172 160x82x10 (9.4) 13.5 0.47 160*82*10 (9.4) 13.5 0.47
Teile-Nr.105169 160x82x6.0 (5.6) 10.5 0.93 160*82*6.0 (5.6) 10.5 0.93
Teile-Nr.105137 140x72x8.0 (7.5) 11.2 0.53 140*72*8.0 (7.5) 11.2 0.53
Teile-Nr.105132 140x72x5.0 (4.7) 9.00 0.97 140*72*5.0 (4.7) 9.00 0.97
Teile-Nr.105116
Teile-Nr.105106
Teile-Nr.105102 125x64x5.0 (4.7) 8.50 0.86 125*64*5.0 (4.7) 8.50 0.86
Teile-Nr.105092
Teile-Nr.105091
Teile-Nr.105085
Teile-Nr.105078 125x41x4.0 (3.75) 8.20 1.24 125*41*4.0 (3.75) 8.20 1.24
Teile-Nr.105061 100x51x5.0 (4.75) 7.80 0.68 100*51*5.0 (4.75) 7.80 0.68
Teile-Nr.105058 100x51x4.0 (3.75) 7.00 0.92 100*51*4.0 (3.75) 7.00 0.92
Teile-Nr.105056 100x41x5.0 (4.75) 7.75 0.67 100*41*5.0 (4.75) 7.75 0.67
Teile-Nr.105055 100x41x4.0 (3.75) 7.20 0.97 100*41*4.0 (3.75) 7.20 0.97
Teile-Nr.105048 90x46x5.0 (4.7) 7.00 0.53 90*46*5.0 (4.7) 7.00 0.53
Teile-Nr.105036 80x41x5.0 (4.70) 6.70 0.55 80*41*5.0 (4.70) 6.70 0.55
Teile-Nr.105017
Teile-Nr.105003 150x61x5.0 10.3 1.06 150*61*5.0 10.3 1.06
Teile-Nr.105002 125x71x6.0 (5.6) 9.30 0.71 125*71*6.0 (5.6) 9.30 0.71
Teile-Nr.105002 125x71x6.0 (5.6) 9.30 0.71 125*71*6.0 (5.6) 9.30 0.71
Teile-Nr.105001 125x64x6.0 (5.6) 9.60 0.77 125*64*6.0 (5.6) 9.60 0.77
Teile-Nr.105001 125x64x6.0 (5.6) 9.60 0.77 125*64*6.0 (5.6) 9.60 0.77
Teile-Nr.105000 125x61x6.0 (5.6) 9.60 0.77 125*61*6.0 (5.6) 9.60 0.77
Teile-Nr.105000 125x61x6.0 (5.6) 9.60 0.77 125*61*6.0 (5.6) 9.60 0.77
Teile-Nr.104999 125x61x5.0 (4.7) 9.00 0.97 125*61*5.0 (4.7) 9.00 0.97
Teile-Nr.104999 125x61x5.0 (4.7) 9.00 0.97 125*61*5.0 (4.7) 9.00 0.97
Teile-Nr.104997 125x51x5.0 (4.7) 8.90 0.95 125*51*5.0 (4.7) 8.90 0.95
Teile-Nr.104997 125x51x5.0 (4.7) 8.90 0.95 125*51*5.0 (4.7) 8.90 0.95
Teile-Nr.104993 100x51x5.0 7.80 0.56 100*51*5.0 7.80 0.56
Teile-Nr.104990 100x41x5.0 7.75 0.55 100*41*5.0 7.75 0.55
Teile-Nr.10498 80x36x4.0 6.20 0.55 80*36*4.0 6.20 0.55
Teile-Nr.104985 70 x40.5x5.0 (4.6) 6.20 0.39 70 *40.5*5.0 (4.6) 6.20 0.39
Teile-Nr.104985 70 x40.5x5.0 (4.6) 6.20 0.39 70 *40.5*5.0 (4.6) 6.20 0.39
Teile-Nr.104980 180x92x6.0 11.1 0.85 180*92*6.0 11.1 0.85
Teile-Nr.104979 180x92x4.8 11.0 1.29 180*92*4.8 11.0 1.29
Teile-Nr.104978 160x82x6.0 10.5 0.75 160*82*6.0 10.5 0.75
Teile-Nr.104976 140x72x5.0 9.00 0.80 140*72*5.0 9.00 0.80
Teile-Nr.104974 140x72x3.8 8.70 1.29 140*72*3.8 8.70 1.29
Teile-Nr.104973 125x64x5.0 8.50 0.70 125*64*5.0 8.50 0.70
Teile-Nr.104965 125x64x3.5 8.00 1.29 125*64*3.5 8.00 1.29
Teile-Nr.104954 100x51x6.0 8.20 0.37 100*51*6.0 8.20 0.37
Teile-Nr.104951 100x51x3.5 6.30 0.80 100*51*3.5 6.30 0.80
Teile-Nr.104946 90x46x5.0 7.00 0.40 90*46*5.0 7.00 0.40
Teile-Nr.104942 90x46x3.5 6.00 0.71 90*46*3.5 6.00 0.71
Teile-Nr.104928 80x41x5.0 6.70 0.34 80*41*5.0 6.70 0.34
Teile-Nr.104921 80x41x2.25 5.20 1.31 80*41*2.25 5.20 1.31
Teile-Nr.104918 80x36x3.0 5.70 0.90 80*36*3.0 5.70 0.90
Teile-Nr.104917 80x31x3.0 5.50 0.83 80*31*3.0 5.50 0.83
Teile-Nr.104913 80x31x2.5 5.30 1.12 80*31*2.5 5.30 1.12
Teile-Nr.104903 71x36x2.5 4.50 0.80 71*36*2.5 4.50 0.80
Teile-Nr.104890 70 x35.5x3.0 5.10 0.70 70 *35.5*3.0 5.10 0.70
Teile-Nr.104889 70 x30.5x3.0 5.10 0.70 70 *30.5*3.0 5.10 0.70
Teile-Nr.104886 70 x30.5x2.5 4.90 0.96 70 *30.5*2.5 4.90 0.96
Teile-Nr.104882 70 x25.5x2.0 4.50 1.25 70 *25.5*2.0 4.50 1.25
Teile-Nr.104876 63x31x3.0 4.80 0.60 63*31*3.0 4.80 0.60
Teile-Nr.104870 63x31x2.5 4.25 0.70 63*31*2.5 4.25 0.70
Teile-Nr.104868 63x31x1.8 4.15 1.31 63*31*1.8 4.15 1.31
Teile-Nr.104853 60 x30.5x3.0 4.70 0.57 60 *30.5*3.0 4.70 0.57
Teile-Nr.104849 60 x30.5x2.75 4.75 0.73 60 *30.5*2.75 4.75 0.73
Teile-Nr.104836 60 x25.5x3.0 4.65 0.55 60 *25.5*3.0 4.65 0.55
Teile-Nr.104830 60 x20.4x3.0 4.70 0.57 60 *20.4*3.0 4.70 0.57
Teile-Nr.104827 60 x20.4x2.5 4.30 0.72 60 *20.4*2.5 4.30 0.72
Teile-Nr.104818 56 x28.5x3.0 4.30 0.43 56 *28.5*3.0 4.30 0.43
Teile-Nr.104790 50 x25.4x3.0 4.10 0.37 50 *25.4*3.0 4.10 0.37
Teile-Nr.104778 50 x25.4x2.25 3.75 0.67 50 *25.4*2.25 3.75 0.67
Teile-Nr.104774 50 x25.4x2.0 3.40 0.70 50 *25.4*2.0 3.40 0.70
Teile-Nr.104766 50 x25.4x1.25 2.85 1.28 50 *25.4*1.25 2.85 1.28
Teile-Nr.104754 50 x20.4x2.5 3.85 0.54 50 *20.4*2.5 3.85 0.54
Teile-Nr.104752 50 x20.4x2.0 3.50 0.75 50 *20.4*2.0 3.50 0.75
Teile-Nr.104750 50 x18.3x3.0 4.00 0.33 50 *18.3*3.0 4.00 0.33
Teile-Nr.104746 50 x18.3x2.0 3.50 0.75 50 *18.3*2.0 3.50 0.75
Teile-Nr.104742 50 x18.3x1.5 3.30 1.20 50 *18.3*1.5 3.30 1.20
Teile-Nr.104741 50 x18.3x1.25 2.85 1.28 50 *18.3*1.25 2.85 1.28
Teile-Nr.104705 40 x20.4x2.25 3.15 0.40 40 *20.4*2.25 3.15 0.40
Teile-Nr.104699 40 x20.4x2.0 3.10 0.55 40 *20.4*2.0 3.10 0.55
Teile-Nr.104694 40 x20.4x1.5 2.65 0.77 40 *20.4*1.5 2.65 0.77
Teile-Nr.104692 40 x18.3x2.0 3.15 0.58 40 *18.3*2.0 3.15 0.58
Teile-Nr.104684 40 x16.3x2.0 3.10 0.55 40 *16.3*2.0 3.10 0.55
Teile-Nr.104682 40 x16.3x1.5 2.80 0.87 40 *16.3*1.5 2.80 0.87
Teile-Nr.104681 40 x14.2x2.0 3.05 0.53 40 *14.2*2.0 3.05 0.53
Teile-Nr.104680 40 x14.2x1.5 2.75 0.83 40 *14.2*1.5 2.75 0.83
Teile-Nr.104669 35.5x18.3x2.0 2.80 0.40 35.5*18.3*2.0 2.80 0.40
Teile-Nr.104658 34 x16.3x2.0 2.85 0.43 34 *16.3*2.0 2.85 0.43
Teile-Nr.104651 34 x16.3x1.5 2.55 0.70 34 *16.3*1.5 2.55 0.70
Teile-Nr.104646 34 x14.3x1.5 2.55 0.70 34 *14.3*1.5 2.55 0.70
Teile-Nr.104639 34 x12.2x1.5 2.50 0.67 34 *12.2*1.5 2.50 0.67
Teile-Nr.104627 34 x12.2x1.0 2.25 1.25 34 *12.2*1.0 2.25 1.25
Teile-Nr.104627 34 x12.2x1.0 2.25 1.25 34 *12.2*1.0 2.25 1.25
Teile-Nr.104611 31.5x16.3x1.75 2.45 0.40 31.5*16.3*1.75 2.45 0.40
Teile-Nr.104611 31.5x16.3x1.75 2.45 0.40 31.5*16.3*1.75 2.45 0.40
Teile-Nr.104599 31.5x12.2x1.5 2.35 0.57 31.5*12.2*1.5 2.35 0.57
Teile-Nr.104592 28 x14.2x1.5 2.15 0.43 28 *14.2*1.5 2.15 0.43
Teile-Nr.104586 28 x12.2x1.5 2.25 0.50 28 *12.2*1.5 2.25 0.50
Teile-Nr.104579 28 x10.2x1.5 2.20 0.47 28 *10.2*1.5 2.20 0.47
Teile-Nr.104565 25 x12.2x1.5 2.05 0.37 25 *12.2*1.5 2.05 0.37
Teile-Nr.104550 23 x10.2x1.25 1.90 0.52 23 *10.2*1.25 1.90 0.52
Teile-Nr.104535 40 x20.4x1.0 2.30 1.30 40 *20.4*1.0 2.30 1.30
Teile-Nr.104533
Teile-Nr.104532 31.5x12.2x1.0 2.10 1.10 31.5*12.2*1.0 2.10 1.10
Teile-Nr.104529 28 x12.2x1.0 1.95 0.95 28 *12.2*1.0 1.95 0.95
Teile-Nr.104528 28 x10.2x1.0 1.90 0.90 28 *10.2*1.0 1.90 0.90
Teile-Nr.104526 25 x12.2x1.0 1.80 0.80 25 *12.2*1.0 1.80 0.80
Teile-Nr.104525 25 x10.2x1.0 1.75 0.75 25 *10.2*1.0 1.75 0.75
Teile-Nr.104524 23 x12.2x1.0 1.60 0.60 23 *12.2*1.0 1.60 0.60
Teile-Nr.104522
Teile-Nr.104521 23x8.2x1.0 1.70 0.70 23*8.2*1.0 1.70 0.70
Teile-Nr.104520 20 x10.2x1.2 1.55 0.29 20 *10.2*1.2 1.55 0.29
Teile-Nr.104518 20 x10.2x1.1 1.55 0.41 20 *10.2*1.1 1.55 0.41
Teile-Nr.104513 20 x10.2x1.0 1.55 0.55 20 *10.2*1.0 1.55 0.55
Teile-Nr.104506 20 x10.2x0.4 0.90 1.25 20 *10.2*0.4 0.90 1.25
Teile-Nr.104506 20 x10.2x0.4 0.90 1.25 20 *10.2*0.4 0.90 1.25
Teile-Nr.104504 18x9.2x1 1.40 0.40 18*9.2*1 1.40 0.40
Teile-Nr.104499 18x8.2x1.0 1.40 0.40 18*8.2*1.0 1.40 0.40
Teile-Nr.104498 35.5x18.3x0.9 2.05 1.28 35.5*18.3*0.9 2.05 1.28
Teile-Nr.104488 31.5x16.3x0.8 1.85 1.31 31.5*16.3*0.8 1.85 1.31
Teile-Nr.104486 28 x14.2x0.8 1.80 1.25 28 *14.2*0.8 1.80 1.25
Teile-Nr.104484 28 x10.2x0.8 1.75 1.19 28 *10.2*0.8 1.75 1.19
Teile-Nr.104480 25 x12.2x0.9 1.60 0.78 25 *12.2*0.9 1.60 0.78
Teile-Nr.104478 25 x12.2x0.7 1.60 1.29 25 *12.2*0.7 1.60 1.29
Teile-Nr.104477 23 x10.2x1.0 1.70 0.70 23 *10.2*1.0 1.70 0.70
Teile-Nr.104477 23 x10.2x1.0 1.70 0.70 23 *10.2*1.0 1.70 0.70
Teile-Nr.104474 23x8.2x0.9 1.60 0.78 23*8.2*0.9 1.60 0.78
Teile-Nr.104470 23x8.2x0.8 1.55 0.94 23*8.2*0.8 1.55 0.94
Teile-Nr.104468 23x8.2x0.7 1.50 1.14 23*8.2*0.7 1.50 1.14
Teile-Nr.104464 22.5x11.2x0.6 1.4 1.33 22.5*11.2*0.6 1.4 1.33
Teile-Nr.104463 20 x10.2x0.9 1.45 0.61 20 *10.2*0.9 1.45 0.61
Teile-Nr.104450 20x8.2x0.9 1.45 0.61 20*8.2*0.9 1.45 0.61
Teile-Nr.104447 20x8.2x0.8 1.40 0.75 20*8.2*0.8 1.40 0.75
Teile-Nr.104445
Teile-Nr.104444 20x8.2x0.7 1.35 0.93 20*8.2*0.7 1.35 0.93
Teile-Nr.104444 20x8.2x0.7 1.35 0.93 20*8.2*0.7 1.35 0.93
Teile-Nr.104441 20x8.2x0.5 1.15 1.30 20*8.2*0.5 1.15 1.30
Teile-Nr.104439 18x9.2x0.7 1.20 0.71 18*9.2*0.7 1.20 0.71
Teile-Nr.104437 18x9.2x0.45 1.05 1.33 18*9.2*0.45 1.05 1.33
Teile-Nr.104431 18x8.2x0.7 1.25 0.79 18*8.2*0.7 1.25 0.79
Teile-Nr.104428 18x8.2x0.5 1.10 1.20 18*8.2*0.5 1.10 1.20
Teile-Nr.104426 18x6.2x0.8 1.30 0.63 18*6.2*0.8 1.30 0.63
Teile-Nr.104422 18x6.2x0.6 1.20 1.00 18*6.2*0.6 1.20 1.00
Teile-Nr.104420 18x6.2x0.5 1.10 1.20 18*6.2*0.5 1.10 1.20
Teile-Nr.104410 16x8.2x0.9 1.25 0.39 16*8.2*0.9 1.25 0.39
Teile-Nr.104408 16x8.2x0.8 1.20 0.50 16*8.2*0.8 1.20 0.50
Teile-Nr.104407 16x8.2x0.7 1.15 0.64 16*8.2*0.7 1.15 0.64
Teile-Nr.104397 16x8.2x0.4 0.90 1.25 16*8.2*0.4 0.90 1.25
Teile-Nr.104395 15x8.2x0.8 1.20 0.50 15*8.2*0.8 1.20 0.50
Teile-Nr.104390 15x8.2x0.7 1.10 0.57 15*8.2*0.7 1.10 0.57
Teile-Nr.104389
Teile-Nr.104386 15x6.2x0.7 1.10 0.57 15*6.2*0.7 1.10 0.57
Teile-Nr.104386
Teile-Nr.104384 15x6.2x0.5 1.00 1.00 15*6.2*0.5 1.00 1.00
Teile-Nr.104383 15x5.2x0.7 1.1 0.57 15*5.2*0.7 1.1 0.57
Teile-Nr.104381 15x5.2x0.5 1.0 1.00 15*5.2*0.5 1.0 1.00
Teile-Nr.104379 15x5.2x0.4 0.95 1.38 15*5.2*0.4 0.95 1.38
Teile-Nr.104374 14x7.2x0.8 1.1 0.38 14*7.2*0.8 1.1 0.38
Teile-Nr.104372 14x7.2x0.5 0.90 0.80 14*7.2*0.5 0.90 0.80
Teile-Nr.104369 14x7.2x0.35 0.80 1.29 14*7.2*0.35 0.80 1.29
Teile-Nr.104361 12.5x6.2x0.7 1.0 0.43 12.5*6.2*0.7 1.0 0.43
Teile-Nr.104358 12.5x6.2x0.5 0.85 0.70 12.5*6.2*0.5 0.85 0.70
Teile-Nr.104354 12.5x6.2x0.35 0.80 1.29 12.5*6.2*0.35 0.80 1.29
Teile-Nr.104353 12.5x 5.2x0.5 0.85 0.70 12.5* 5.2*0.5 0.85 0.70
Teile-Nr.104351
Teile-Nr.104347 12x6.2x0.6 0.95 0.58 12*6.2*0.6 0.95 0.58
Teile-Nr.104347
Teile-Nr.104345 12x5.2x0.6 0.95 0.58 12*5.2*0.6 0.95 0.58
Teile-Nr.104342 12x5.2x0.5 0.90 0.80 12*5.2*0.5 0.90 0.80
Teile-Nr.104338 12x4.2x0.5 0.85 0.70 12*4.2*0.5 0.85 0.70
Teile-Nr.104326
Teile-Nr.104323 10x4.2x0.6 0.85 0.42 10*4.2*0.6 0.85 0.42
Teile-Nr.104323 10x4.2x0.6 0.85 0.42 10*4.2*0.6 0.85 0.42
Teile-Nr.104319 10x3.2x0.5 0.75 0.50 10*3.2*0.5 0.75 0.50
Teile-Nr.104317 10x3.2x0.3 0.65 1.17 10*3.2*0.3 0.65 1.17
Teile-Nr.104310 8x4.2x0.3 0.55 0.83 8*4.2*0.3 0.55 0.83
Teile-Nr.104308 8x4.2x0.2 0.45 1.25 8*4.2*0.2 0.45 1.25
Teile-Nr.104306 8x3.2x0.5 0.70 0.40 8*3.2*0.5 0.70 0.40
Teile-Nr.104301 8x3.2x0.3 0.55 0.83 8*3.2*0.3 0.55 0.83
Teile-Nr.104299 8x3.2x0.2 0.40 1.00 8*3.2*0.2 0.40 1.00
Teile-Nr.104298 6x3.2x0.3 0.45 0.50 6*3.2*0.3 0.45 0.50
Teile-Nr. 104332 10x5.2x0.5 0.75 0.50 10*5.2*0.5 0.75 0.50
Teile-Nr. 104 336 12x4.2x0.4 0.80 1.00 12*4.2*0.4 0.80 1.00
8x3.2x0.4 0.60 0.50 8*3.2*0.4 0.60 0.50
8x4.2x0.4 0.60 0.50 8*4.2*0.4 0.60 0.50
10x3.2x0.4 0.70 0.75 10*3.2*0.4 0.70 0.75
10x4.2x0.4 0.70 0.75 10*4.2*0.4 0.70 0.75
10x4.2x0.5 0.75 0.50 10*4.2*0.5 0.75 0.50
10x5.2x0.25 0.55 1.20 10*5.2*0.25 0.55 1.20
10x5.2x0.4 0.70 0.75 10*5.2*0.4 0.70 0.75
12x4.2x0.6 1.0 0.67 12*4.2*0.6 1.0 0.67
12x6.2x0.5 0.85 0.70 12*6.2*0.5 0.85 0.70
15x5.2x0.6 1.05 0.75 15*5.2*0.6 1.05 0.75
15x6.2x0.6 1.05 0.75 15*6.2*0.6 1.05 0.75
16x8.2x0.6 1.05 0.75 16*8.2*0.6 1.05 0.75
18x6.2x0.4 1.00 1.50 18*6.2*0.4 1.00 1.50
18x6.2x0.7 1.25 0.79 18*6.2*0.7 1.25 0.79
18x8.2x0.8 1.30 0.63 18*8.2*0.8 1.30 0.63
20x8.2x0.6 1.30 1.17 20*8.2*0.6 1.30 1.17
20x8.2x1 1.55 0.55 20*8.2*1 1.55 0.55
20 x10.2x0.5 1.15 1.30 20 *10.2*0.5 1.15 1.30
20 x10.2x0.8 1.35 0.69 20 *10.2*0.8 1.35 0.69
20 x10.2x1.5 1.80 0.20 20 *10.2*1.5 1.80 0.20
22.5x11.2x0.8 1.45 0.81 22.5*11.2*0.8 1.45 0.81
22.5x11.2x1.25 1.75 0.40 22.5*11.2*1.25 1.75 0.40
23 x10.2x0.9 1.65 0.83 23 *10.2*0.9 1.65 0.83
23 x12.2x1.25 1.85 0.48 23 *12.2*1.25 1.85 0.48
23 x12.2x1.5 2.10 0.40 23 *12.2*1.5 2.10 0.40
25 x12.2x1.25 1.95 0.56 25 *12.2*1.25 1.95 0.56
28 x10.2x1.25 2.05 0.64 28 *10.2*1.25 2.05 0.64
28 x12.2x1.25 2.10 0.68 28 *12.2*1.25 2.10 0.68
28 x14.2x1.0 1.80 0.80 28 *14.2*1.0 1.80 0.80
28 x14.2x1.25 2.10 0.68 28 *14.2*1.25 2.10 0.68
31.5 x12.2x1.25 2.20 0.76 31.5 *12.2*1.25 2.20 0.76
31.5x16.3x1.25 2.15 0.72 31.5*16.3*1.25 2.15 0.72
31.5x16.3x1.5 2.40 0.60 31.5*16.3*1.5 2.40 0.60
31.5 x16.3x2.0 2.75 0.38 31.5 *16.3*2.0 2.75 0.38
34 x12.2x1.25 2.35 0.88 34 *12.2*1.25 2.35 0.88
34 x14.3x1.25 2.40 0.92 34 *14.3*1.25 2.40 0.92
35.5 x18.3x1.25 2.25 0.80 35.5 *18.3*1.25 2.25 0.80
40 x14.2x1.25 2.65 1.12 40 *14.2*1.25 2.65 1.12
40 x20.5x2.5 3.45 0.38 40 *20.5*2.5 3.45 0.38
45 x22.4x1.25 2.85 1.28 45 *22.4*1.25 2.85 1.28
45 x22.4x1.75 3.05 0.74 45 *22.4*1.75 3.05 0.74
45 x22.4x2.5 3.50 0.40 45 *22.4*2.5 3.50 0.40
50 x18.3x2.5 3.85 0.54 50 *18.3*2.5 3.85 0.54
50 x22.4x2.0 3.60 0.80 50 *22.4*2.0 3.60 0.80
50 x22.4x2.5 3.90 0.56 50 *22.4*2.5 3.90 0.56
50 x25.4x1.5 3.10 1.07 50 *25.4*1.5 3.10 1.07
50 x25.4x2.5 3.90 0.56 50 *25.4*2.5 3.90 0.56
56 x28.5x1.5 3.45 1.30 56 *28.5*1.5 3.45 1.30
56 x28.5x2.0 3.60 0.80 56 *28.5*2.0 3.60 0.80
56 x28.5x2.5 4.20 0.68 56 *28.5*2.5 4.20 0.68
60 x20.4x2.0 4.10 1.05 60 *20.4*2.0 4.10 1.05
60 x25.5x2.5 4.40 0.76 60 *25.5*2.5 4.40 0.76
60 x30.5x2.5 4.50 0.80 60 *30.5*2.5 4.50 0.80
60 x30.5x3.5 5.0 0.43 60 *30.5*3.5 5.0 0.43
63x31x3.5 4.90 0.40 63*31*3.5 4.90 0.40
70 x35.5x3.5 5.30 0.51 70 *35.5*3.5 5.30 0.51
70 x35.5x4.0 5.80 0.45 70 *35.5*4.0 5.80 0.45
70 x35.5x4.0 (3.75) 5.80 0.59 70 *35.5*4.0 (3.75) 5.80 0.59
70 x40.5x4.0 5.60 0.40 70 *40.5*4.0 5.60 0.40
70 x40.5x4.0 (3.75) 5.60 0.53 70 *40.5*4.0 (3.75) 5.60 0.53
70 x40.5x5.0 6.20 0.24 70 *40.5*5.0 6.20 0.24
71x36x2.0 4.60 1.30 71*36*2.0 4.60 1.30
71x36x4.0 5.60 0.40 71*36*4.0 5.60 0.40
71x36x4.0 (3.75) 5.60 0.53 71*36*4.0 (3.75) 5.60 0.53
80x31x4.0 6.10 0.53 80*31*4.0 6.10 0.53
80x31x4.0 (3.75) 6.10 0.67 80*31*4.0 (3.75) 6.10 0.67
80x36x4.0 (3.75) 6.20 0.70 80*36*4.0 (3.75) 6.20 0.70
80x41x3.0 5.30 0.77 80*41*3.0 5.30 0.77
80x41x4.0 6.20 0.55 80*41*4.0 6.20 0.55
80x41x4.0 (3.75) 6.20 0.70 80*41*4.0 (3.75) 6.20 0.70
90x46x2.5 5.70 1.28 90*46*2.5 5.70 1.28
100x41x4.0 7.20 0.80 100*41*4.0 7.20 0.80
100x51x2.7 6.20 1.30 100*51*2.7 6.20 1.30
100x51x4.0 7.00 0.75 100*51*4.0 7.00 0.75
100x51x6.0 (5.6) 8.20 0.50 100*51*6.0 (5.6) 8.20 0.50
112x57x3.0 6.90 1.30 112*57*3.0 6.90 1.30
112x57x4.0 7.20 0.80 112*57*4.0 7.20 0.80
112x57x4.0 (3.75) 7.20 0.97 112*57*4.0 (3.75) 7.20 0.97
112x57x6.0 8.50 0.42 112*57*6.0 8.50 0.42
112x57x6.0 (5.6) 8.50 0.56 112*57*6.0 (5.6) 8.50 0.56
125x41x4.0 8.20 1.05 125*41*4.0 8.20 1.05
125x51x4.0 8.50 1.13 125*51*4.0 8.50 1.13
125x51x4.0 (3.75) 8.50 1.33 125*51*4.0 (3.75) 8.50 1.33
125x51x5.0 8.90 0.78 125*51*5.0 8.90 0.78
125x51x6.0 9.40 0.57 125*51*6.0 9.40 0.57
125x51x6.0 (5.6) 9.40 0.73 125*51*6.0 (5.6) 9.40 0.73
125x61x5.0 9.00 0.80 125*61*5.0 9.00 0.80
125x61x6.0 9.60 0.60 125*61*6.0 9.60 0.60
125x61x8.0 (7.6) 10.9 0.46 125*61*8.0 (7.6) 10.9 0.46
125x64x6.0 9.60 0.60 125*64*6.0 9.60 0.60
125x64x7.0 (6.55) 10.0 0.57 125*64*7.0 (6.55) 10.0 0.57
125x64x8.0 (7.5) 10.6 0.45 125*64*8.0 (7.5) 10.6 0.45
125x71x6.0 9.30 0.55 125*71*6.0 9.30 0.55
125x71x8.0 (7.4) 10.4 0.45 125*71*8.0 (7.4) 10.4 0.45
125x71x10 (9.2) 11.8 0.32 125*71*10 (9.2) 11.8 0.32
140x72x3.8 (3.8) 8.70 1.37 140*72*3.8 (3.8) 8.70 1.37
150x61x5.0 (4.8) 10.3 1.18 150*61*5.0 (4.8) 10.3 1.18
150x61x6.0 10.8 0.80 150*61*6.0 10.8 0.80
150x61x6.0 (5.8) 10.8 0.89 150*61*6.0 (5.8) 10.8 0.89
150x71x6.0 10.8 0.80 150*71*6.0 10.8 0.80
150x71x6.0 (5.65) 10.8 0.96 150*71*6.0 (5.65) 10.8 0.96
150x71x8.0 (7.5) 12.0 0.64 150*71*8.0 (7.5) 12.0 0.64
150x81x8.0 (7.5) 11.7 0.60 150*81*8.0 (7.5) 11.7 0.60
150x81x10 (9.3) 13.0 0.44 150*81*10 (9.3) 13.0 0.44
160x82x4.3 9.90 1.30 160*82*4.3 9.90 1.30
160x82x4.3 (4.3) 9.90 1.38 160*82*4.3 (4.3) 9.90 1.38
180x92x13 (12.1) 16.5 0.40 180*92*13 (12.1) 16.5 0.40
200x82x8.0 (7.6) 14.2 0.91 200*82*8.0 (7.6) 14.2 0.91
200x82x10 (9.45) 15.5 0.68 200*82*10 (9.45) 15.5 0.68
200x82x12 (11.35) 16.6 0.49 200*82*12 (11.35) 16.6 0.49
200x92x10 (9.5) 15.6 0.68 200*92*10 (9.5) 15.6 0.68
200x92x12 (11.4) 16.8 0.50 200*92*12 (11.4) 16.8 0.50
200x92x14 (13.2) 18.1 0.40 200*92*14 (13.2) 18.1 0.40
200x102x5.5 12.5 1.27 200*102*5.5 12.5 1.27
200x102x8.0 (7.5) 13.6 0.87 200*102*8.0 (7.5) 13.6 0.87
200x102x10 (9.4) 15.6 0.70 200*102*10 (9.4) 15.6 0.70
200x102x12 (11.25) 16.2 0.48 200*102*12 (11.25) 16.2 0.48
200x102x14 (13.1) 18.2 0.42 200*102*14 (13.1) 18.2 0.42
200x112x12 (11.1) 16.2 0.50 200*112*12 (11.1) 16.2 0.50
200x112x14 (12.9) 17.5 0.40 200*112*14 (12.9) 17.5 0.40
200x112x16 (14.7) 18.8 0.31 200*112*16 (14.7) 18.8 0.31
225x112x8.0 (7.5) 14.5 0.99 225*112*8.0 (7.5) 14.5 0.99
225x112x12 (11.25) 17.0 0.55 225*112*12 (11.25) 17.0 0.55
225x112x16 (15) 20.5 0.40 225*112*16 (15) 20.5 0.40
250x102x10 (9.7) 18.0 0.88 250*102*10 (9.7) 18.0 0.88
250x102x12 (11.25) 19.0 0.74 250*102*12 (11.25) 19.0 0.74
250x127x6.5 (6.5) 14.8 1.35 250*127*6.5 (6.5) 14.8 1.35
250x127x7.0 (6.7) 14.8 1.25 250*127*7.0 (6.7) 14.8 1.25
250x127x10 (9.4) 17.0 0.86 250*127*10 (9.4) 17.0 0.86
400x201.2x22.2 (22.2) 31.0 0.43 400*201.2*22.2 (22.2) 31.0 0.43
425x216.2x23.6 (23.6) 32.9 0.42 425*216.2*23.6 (23.6) 32.9 0.42
475x241.2x26.4 (26.4) 36.8 0.42 475*241.2*26.4 (26.4) 36.8 0.42
450x231.2x25.0 (25.0) 34.8 0.42 450*231.2*25.0 (25.0) 34.8 0.42
500x251.4x27.8 (27.8) 38.8 0.42 500*251.4*27.8 (27.8) 38.8 0.42
530x271.4x29.5 (29.5) 41.1 0.42 530*271.4*29.5 (29.5) 41.1 0.42
600x301.4x33.3 (33.3) 46.6 0.43 600*301.4*33.3 (33.3) 46.6 0.43
560x281.4x31.1 (31.1) 43.5 0.43 560*281.4*31.1 (31.1) 43.5 0.43
12x6.2x0.6 0.95 0.58 12*6.2*0.6 0.95 0.58
15x6.2x0.7 1.10 0.57 15*6.2*0.7 1.10 0.57
源自:深圳市湾边贸易有限公司
备注:产品价格与描述不同,具体请来电咨询!
电话:86 0755 86216601
传真:86 0755 86216602
邮编:518110
邮箱:info(at)coastaltrading.com.cn
